Gravity LED Pro6 Light Bars 20" to 57"- by KC Hilites

Make your dark path shine with the Gravity LED Pro6 Light Bars by KC Hilites. Mounted at the top of your off-road vehicle, this LED can easily be transformed to your orientation preference, whether a straight or curved arrangement, to adjust to your liking.

You can never go wrong as to how many Gravity LED Pro6 you will have for your all-terrain vehicle. Available in 7 variants, you can choose from a 3-Light bar to a 9-Light bar, all with blacklight covers bearing the yellow KC Hilites logo.

This LED system is powered by G6 LED optical insert, an original technology from KC Hilites, which assures that actual emitted light output is being maximized in creating powerful, usable light every off-road use. The combo beam pattern of the Gravity LED Pro6 provides a better range of visibility and homogenous light beam shape, for more utilized light coverage.

Free Shipping!

PATENTED GRAVITY® REFLECTIVE DIODE TECHNOLOGY
Powered by KC's G6 LED optical insert, each Gravity LED Pro6 features patented Gravity® Reflective Diode (GRD) technology. This advanced technology and reflector design ensure that actual emitted light output from each LED is being maximized in creating powerful, usable light for everyday off-road use. KC GRD technology strategically positions LEDs inside the reflector so that all light output is being carefully directed and aimed to deliver usable light. What you receive is highly targeted light distribution, providing unparalleled clarity, performance, and beam shape.

PATENTED INFINITY RING™ SYSTEM
The Gravity LED Pro6 allows you to take full control of your specific lighting needs. Pro6 LED light bar features a patented Infinity Ring™ system utilizing individual rings to securely link individual 6" Pro6 LED lights together to form a rigid, powerful LED light bar system. The unique hinge and bolt design in every ring allow for endless modularity, expandability, and adjustability to suit your lighting needs. This means the seamless transition between straight, radius, or hybrid radius light bar orientations to angle lights exactly how you see fit.

COMBO BEAM PATTERN FOR COMPLETE LIGHTING COVERAGE
Gravity LED Pro6 light bars are specifically configured using a combination of SAE/ECE Driving and Wide-40 G6 LED optical inserts. The combination of different reflector optics provides a broader range of visibility and homogenous light beam shape, for more usable lighting coverage. Driving Beam lights provide powerful forward distance and equal beam distribution width, while the Wide-40 beam offers a wider area of coverage, increasing side to side peripheral visibility. This not only results in incredible light output distance but also evenly balanced light distribution and beam shape that translates to light output that you can actually use for all of your off-road lighting adventures.

Features:

Patented Pro6 Infinity Ring™ System: Easily transform the Pro6 light bar between straight or curved light orientations
Every Pro6 is powered by KC patented Gravity® Reflective Diode (GRD) technology for unparalleled beam shape, light performance and clarity
Gravity® G6 LED reflector optics utilizing a combination of Driving and Wide-40 Beam pattern lights for optimal lighting balance and performance
Modular design is expandable to different size widths and beam patterns to suit specific applications
Light Bar Systems Available in 7 different variations: 20" 3-Ring, 26" 4-Ring, 32" 5-Ring, 39" 6-Ring, 45" 7-Ring, 50" 8-Ring, and 57" 9-Ring widths (Vehicle specific kits also available)

Light Performance:

Raw Lumens:

20" 3-Ring = 6,900 lm
26" 4-Ring = 9,200 lm
32" 5-Ring = 11,500 lm
39" 6-Ring = 13,800 lm
45" 7-Ring = 16,100 lm
50" 8-Ring = 18,400 lm
57" 9-Ring = 23,009 lm

Lux @ 10meters:

20" 3-Ring = 2,794 lx
26" 4-Ring = 3,425 lx
32" 5-Ring = 4,200 lx
39" 6-Ring = 5,150 lx
45" 7-Ring = 6,100 lx
50" 8-Ring = 6,700 lx
57" 9-Ring= 7,500 lx

Candela:

20" 3-Ring = 279,400 cd
26" 4-Ring = 342,500 cd
32" 5-Ring = 420,000 cd
39" 6-Ring = 515,000 cd
45" 7-Ring = 610,000 cd
50" 8-Ring = 670,000 cd
57" 9-Ring = 750,000 cd

Beam Distance (Meters):

20" 3-Ring = 1,057m
26" 4-Ring = 1,170m
32" 5-Ring = 1,296m
39" 6-Ring = 1,435m
45" 7-Ring = 1,562m
50" 8-Ring = 1,637m
57" 9-Ring = 1,732m

Dimensions:

20” 3-Light = H - 6.06" x D - 3.33" x W - 20.325" (Straight) / 20.301" (Curved)
26” 4-Light = H - 6.06" x D - 3.33" x W - 26.575" (Straight) / 26.556" (Curved)
32” 5-Light = H - 6.06" x D - 3.33" x W - 32.875" (Straight) / 32.708" (Curved)
39” 6-Light = H - 6.06" x D - 3.33" x W - 39.125" (Straight) / 38.871" (Curved)
45” 7-Light = H - 6.06" x D - 3.33" x W - 45.38" (Straight) / 44.999" (Curved)
50” 8-Light = H - 6.06" x D - 3.33" x W - 51.625" (Straight) / 51.086" (Curved)
57” 9-Light = H - 6.06" x D - 3.33" x W - 57.625" (Straight) / 57.128" (Curved)

Available Part Numbers:

Gravity® LED Pro6 3-Light 20" Universal Combo LED Light Bar - #91318
Gravity® LED Pro6 4-Light 26" Universal Combo LED Light Bar - #91319
Gravity® LED Pro6 5-Light 32" Universal Combo LED Light Bar without Light Mounts - #91306
Gravity® LED Pro6 6-Light 39" Universal Combo LED Light Bar without Light Mounts - #91307
Gravity® LED Pro6 8-Light 50" Universal Combo LED Light Bar without Light Mounts - #91308
Gravity® LED Pro6 Polaris RZR 5-Light 32" Combo LED Light Bar with Light Mounts - #91309
Gravity® LED Pro6 Yamaha YXZ1000R 6-Light 39" Combo LED Light Bar with Light Mounts - #91310
Gravity® LED Pro6 10-14 Ford F-150/Raptor 8-light 50" Combo LED Light Bar with Light Mounts - #91311
Gravity® LED Pro6 07-18 Jeep JK 8-Light 50" Combo LED Light Bar with Light Mounts - #91313
Gravity® LED Pro6 7-Light 45" Universal Combo LED Light Bar - #91314
Gravity® LED Pro6 9-Light 57" Universal Combo LED Light Bar - #91315
Gravity® LED Pro6 13-16 Can-Am Maverick/Commander 6-Light 39" Combo LED Light Bar with Light Mounts - #91316
Gravity® LED Pro6 14-17 Arctic Cat Wildcat 6-Light 39" Combo LED Light Bar with Light Mounts - #91327
Gravity® LED Pro6 05-18 Toyota Tacoma 8-light Combo LED Light Bar – #91331
Gravity® LED Pro6 17-18 Ford F-150/ Raptor 9-Light 57" Combo LED Light Bar - #91333
Gravity® LED Pro6 17-18 Can-Am Maverick X3 7-Light 45" Combo LED Light Bar - #91334
Gravity® LED Pro6 7-Light 45" Radius Universal Combo LED Light Bar - #91397
Gravity® LED Pro6 8-Light 50" Radius Universal Combo LED Light Bar - #91398
Gravity® LED Pro6 97-06 Jeep TJ 8-Light Combo Beam LED Light Bar - #91337
Gravity® LED Pro6 LED Light Bar - 50" Jeep Wrangler JL & Gladiator JT 8-Ring - #91336
